Class-D Dual-channel Digital amplifiers, bridgeable to be at 8Ω
Dual Source Amplifiers, better sound for TV Amplifiers
Universal in/out 12v triggers as well as zone-specific in/out triggers.
| Item | DPA-275BT | DPA-2100 | DPA-2200BT |
| Output Power (RMS) | 75W*2Ch@4 ohm | 100W*2Ch@4 ohm | 200W*2Ch@4 ohm |
| Power consumption in working mode | 220W max | 260W max | 640W max |
| Function buttons | N/A | Power on/off | Power on/off |
| Trigger function | N/A | Yes | Yes |
| Power consumption in standby mode | ≤0.5W | ≤0.5W | ≤0.5W |
| Bluetooth solution, sensitivity | ATS2853 V5.3, 600mV | N/A | ATS2853 V5.3, 600mV |
| Aux Input sensitivity | 770mV | 680mV | 770mV |
| S/N (A+ weight) | 95dB | 99dB | 95dB |
| Gain | 27dB | 29.4dB | 31.3dB |
| Pre out | Yes | N/A | Yes |
| THD (Rated output: –3 dB) | 0.01 %, 4 Ω, 1 kHz | 0.01 %, 4 Ω, 1 kHz | 0.01 %, 4 Ω, 1 kHz |
| Impedance | 10KΩ | 10KΩ | 10KΩ |
| Power consumption in standby mode | ≤0.5W | ≤0.5W | ≤0.5W |
| Frequency Response / Sat channel | 20Hz-20k Hz (-3dB) | 20Hz-20k Hz (-3dB) | 20Hz-20k Hz (-3dB) |
| Crosstalk | 65dB | 65dB | 65dB |
| Product size (mm) | H44*W220*D141 | H44*W435*D166 | H44*W435*D266 |
| Packing Dimensions (mm) | H103*W280*D201 | H148*W525*D270 | H148*W525*D370 |
| Net weight | 1.0 kgs | 2.50 kgs | 4.05 kgs |
| Gross weight | 1.40 kgs | 4.10 kgs | 5.55 kgs |
